AMS 2482 Spec
Teflon Impregnation

What is AMS 2482?

At AOTCO, we offer a wide variety of military and aerospace specs for all our metal finishing processes. AMS 2482 is the Aerospace Material Specification for Type III anodize, or Hardcoat Anodize, with Teflon Impregnation.

Benefits of AMS 2482 Hardcoat Anodize with PTFE

• Provides its substrate with the thickest layer of oxide of all the anodizing processes.
• Combines this increased hardness and strength with the unique lubricity of Teflon.
• The result is a self-lubricating component that is highly resistant to wear, abrasion, and corrosion.
• The anodize process can reveal the presence of metallurgical damage which had occurred prior to the submittal of parts to the anodize processor. Examples are:
  • Damage from improper welding
  • Weld repair of castings after final heat treatment
  • Incorrect initial heat treatment
  • Raw material chemical segregation
  • Other prior metallurgical conditions which may be detrimental to the final use of the component

Technical Notes

Purchase Order shall specify not less than the following

• AMS2482E
• Basis metal to be anodized
• Special features, geometry or processing present on parts that requires special attention by the processor
• Quantity of pieces to be anodized

Classification

The processes covered by this specification are classified as follows:

• Type 1 – PTFE-impregnated aluminum oxide
• Type 2 – Co deposited PTFE and aluminum oxide

Thickness

AMS2482 designates finished coating thickness of 0.002 inch ± 0.0005 (51 µm ± 13). Other coating thicknesses may be specified designating the nominal thickness in thousandths of an inch (25 µm). A tolerance of ±0.0005 inch (±13 µm) in thickness of coating will be allowed. AMS2482-3 designates a finished coating thickness of 0.003 inch ± 0.0005 (76 µm ± 13).

Coating thickness requirements shall not apply to blind holes or recesses with depth greater than twice the diameter or in open holes with depth greater than seven times the diameter unless a specific coating thickness is specified in those areas.

• The purchaser or cognizant engineering organization may elect to place such components on material review pending further testing or analysis.

The anodizing processor shall not be responsible for the presence of these types of metallurgical anomalies occurring prior to submittal of parts for anodizing.
